AL-KO trailer shock absorber universal black 1500/3000kg

AL-KO axle shock absorber

Universal black

The shock absorbers are required for the 100 km/h approval.

AL-KO article number: 282.259

Description:

The dangerous "jumping" is immediately reduced by optimal cushioning. This means more driving stability, more braking stability and optimal ground contact.
The rubber-mounted articulated connection eyes enable a low-wear, tension-free installation position up to 5° inclination.

The screws are firmly integrated in the eye of the damper.

Product features:

- Axle load single axle up to 1500kg
- Axle load tandem axle up to 3000kg
- Installation length min. 255 mm / max. 405 mm
- 2 articulated connection eyes Ø12 mm with bushing length above = 47 mm / below = 40 mm
- for trailing arms
- only for rubber spring axles with installation position in front of the axle in the direction of travel
- Dampening takes place in the direction of compression (not in the direction of tension)
- Not suitable for trailers with coil springs or leaf springs
- incl. fastening screws

If you have any further questions, please contact us.
